6.3V 1500µF ±20% 0.23ohm 360mA 2K Hours UE Series

SMD Aluminum Electrolytic Capacitors, Low Impedance and ESR type, UE series, 2 pads Capacitance: 1500µF, Tolerance ±20%, Voltage 6.3V, Case size: ØD10.0*L10.20mm, Impedance 0.23 Ohm. Ripple Current: 360mA Max. @+105℃, 100KHz Lifetime 2000Hours @105°C, Operating Temp. Range -55°C ~+105°C

Key Features:
  • Series: UE
  • Capacitance: 1500µF
  • Capacitance Tolerance: ±20%
  • Rated Voltage: 6.3V
  • Ripple Current @+105°C, 100KHz: 360mA Max.
  • Lifetime @105°C: 2000 Hours
  • Leakage Current: 94.5(μA)max
  • Impedance @20℃,100KHz: 0.23ohm Max.

$0.58500

Out of stock
SKU UE158M6V3HGKTA
Original MPNCAE158M0JHUEGJ2TR
Datasheet Data Sheet

Description

SMD Aluminum Electrolytic Capacitors, Low Impedance and ESR type, UE series, 2 pads Capacitance: 1500µF, Tolerance ±20%, Voltage 6.3V, Case size: ØD10.0*L10.20mm, Impedance 0.23 Ohm. Ripple Current: 360mA Max. @+105℃, 100KHz Lifetime 2000Hours @105°C, Operating Temp. Range -55°C ~+105°C

  • Polar Aluminum Electrolytic Capacitor (Foil Type)
  • High stability and reliability
  • Lifetime 2000 Hours @ 105°C
  • Designed Capacitor’s Quality Meets IEC60384.
  • Applicable To Automatic Mounting Machine
  • Cross Competitors Parts and more.
  • RoHS Complaint And Halogen Free

APPLICATION

  • High-density Patch Assembly General Electronic Circuit Etc.

Specification

Series

UE

Capacitance

1500µF

Capacitance Tolerance

±20%

Rated Voltage

6.3V

Case Size

ØD10.0*L10.2mm

Ripple Current @+105°C, 100KHz

360mA Max.

Lifetime @105°C

2000 Hours

Operating Temp. Range

-55°C ~+105°C

Dissipation Factor @+20°C, 120Hz Tanδ Max.

0.26 Tanδ Max.

Leakage Current

94.5(μA)max

Impedance @20℃,100KHz

0.23ohm Max.

Mounting Type

Surface Mount, 2 pads

RoHS Status

RoHS III Compliant & Halogen Free

Moisture Sensitivity Level (MSL)

1 (Unlimited)

REACH Status

REACH Unaffected

HTSUS

8532.22.0020

ECCN

EAR99

Standard Package (MPQ)

500pcs/Reel, Quantity entered must be multiple of 500

NCNR

Non-Cancelable/Non-Returnable
