10V, 220μF, ±20%, 300mΩ Max. Polymer Case B

SMD Conductive Polymer Tantalum Capacitors, EIA code 3528-21, CA55 Series, Case B, L3.50*W2.80*H2.10mm, Rated voltage 10Vdc, Capacitance 220μF, Tolerance ±20%, ESR 300 mΩ Max., Operating Temp. Range -55°C ~+125°C.

Key Features:
  • Series: CA55 Series, Case B
  • Capacitance: 220uF
  • Capacitance Tolerance: ±20%
  • Case Size: L3.50*W2.80*H2.10mm
  • Rated Voltage: 10V
  • ESR: 300 mΩ Max
  • Operating Temperature Range: -55°C ~+125°C

$1.15000

Out of stock
SKU CA55B010K227TA
Original MPNCA55-B010M227T
Datasheet Data Sheet

Description

SMD Conductive Polymer Tantalum Capacitors, EIA code 3528-21, CA55 Series, Case B, L3.50*W2.80*H2.10mm, Rated voltage 10Vdc, Capacitance 220μF, Tolerance ±20%, ESR 300 mΩ Max., Operating Temp. Range -55°C ~+125°C.

• RoHS III Compliant
• Wide Operating Temperature Range -55~+125℃
• Small volume, High Stability
• Low ESR Value
• Good Frequency Characteristic

APPLICATION

• For Surface Mount Consumer Electronic Equipment
• Color TV sets, PC, Mobile Telephone sets Pickup camera Radar etc



Specification

Series

CA55 Series, Case B

Capacitance

220uF

Capacitance Tolerance

±20%

Case Size

L3.50*W2.80*H2.10mm

Rated Voltage

10V

Dissipation Factor

10.0% tgδ Max.

ESR

300 mΩ Max

Operating Temperature Range

-55°C ~+125°C

Mounting Type

SMD type, 2 Pads

RoHS Status

RoHS III Compliant & Halogen Free

Moisture Sensitivity Level (MSL)

1 (Unlimited)

REACH Status

REACH Unaffected

HTSUS

8532.22.0020

ECCN

EAR99

Standard Package (MPQ)

2000pcs/reel, Quantity entered must be multiple of 2000

NCNR

Non-Cancelable/Non-Returnable
