25V 82µF ±20% 50 mohm Max. 900mA 4K hours AEC-Q200 BW Series

Conductive Polymer Hybrid Aluminum Electrolytic Capacitors BW series, Capacitance: 82µF, Tolerance ±20%, Voltage 25V, 2 pads, Case size: ØD6.30*L5.80mm, Ripple Current 900mA Max.@+125℃, 100KHz, Lifetime 4000Hours @125°C, ESR @125°C,100KHz: 50 mohm Max., Operating Temp. Range -55°C ~+125°C, Leakage Current: 20.5μA @at 20℃ after 2 minutes

Key Features:
  • Series: BW
  • Capacitance: 82µF
  • Capacitance Tolerance: ±20%
  • Rated Voltage: 25V
  • Impedance @20℃,100KHz: 50mohm Max.
  • Lifetime @125°C: 4000 Hours
  • Rating: AEC-Q200
See Full Specification

$1.98550

Out of stock
SKU BW826M025HEHTA
Original MPNCXE826M1EHBWEE8TRC
Datasheet Data Sheet

Description

Conductive Polymer Hybrid Aluminum Electrolytic Capacitors BW series, Capacitance: 82µF, Tolerance ±20%, Voltage 25V, 2 pads, Case size: ØD6.30*L5.80mm, Ripple Current 900mA Max.@+125℃, 100KHz, Lifetime 4000Hours @125°C, ESR @125°C,100KHz: 50 mohm Max., Operating Temp. Range -55°C ~+125°C, Leakage Current: 20.5μA @at 20℃ after 2 minutes

• Conductive Polymer Hybrid Aluminum Electrolytic Capacitors
• High Stability And Reliability, Low ESR, High Ripple Current
• Long Life 4000 Hours @ 125°C
• Quality and standard Meets IEC 60384-4 and AEC-Q200-REV D
• Applicable To Automatic Mounting Machine
• Cross Competitors PARTS GYA, HZC, ZC And HXC Series And More.
• RoHS III Complaint And Halogen Free

APPLICATION

• For Applications Automotive and more

Specification

Series

BW
Capacitance

82µF
Capacitance Tolerance

±20%
Rated Voltage

25V
Case Size

ØD6.30*L5.80mm
Impedance @20℃,100KHz

50mohm Max.
Ripple Current @+125°C, 100KHz

900mA Max.
Lifetime @125°C

4000 Hours
Operating Temp. Range

-55°C ~+125°C
Dissipation Factor @+20°C, 120KHz

14.0 Tanδ Max.
Leakage Current (μA/2min) µA Max

20.5μA
Mounting Type

Surface Mount, 2 pads
Rating

AEC-Q200
RoHS Status

RoHS III Compliant & Halogen Free
Moisture Sensitivity Level (MSL)

1 (Unlimited)
REACH Status

REACH Unaffected
HTSUS

8532.22.0020
ECCN

EAR99
Standard Package (MPQ)

1000pcs/Reel, Quantity entered must be multiple of 1000
NCNR

Non-Cancelable/Non-Returnable
