35V 100µF ±20% 0.19 ohm Max. 450mA 2K hours UZ Series

SMD Aluminum Electrolytic Capacitors, Extra low Impedance type UZ series, 2 pads Capacitance: 100µF, Tolerance ±20%, Voltage 35V, Case size: ØD8.0*L10.20mm, Impedance 0.19 Ohm., Ripple Current: 450mA Max. @+105℃, 100KHz, Lifetime 2000Hours @105°C, Operating Temp. Range -55°C ~+105°C

Key Features:
  • Series: UZ
  • Capacitance: 100µF
  • Capacitance Tolerance: ±20%
  • Rated Voltage: 35V
  • Impedance @20℃,100KHz: 0.19ohm Max.
  • Ripple Current @+105°C, 100KHz: 450mA Max.
  • Lifetime @105°C: 2000 Hours
  • Leakage Current Max.: 52.5 (μA)max

$0.68500

Out of stock
SKU UZ107M035HFKTA
Original MPNCAE107M1VHUZFJ2TR
Datasheet Data Sheet

Description

SMD Aluminum Electrolytic Capacitors, Extra low Impedance type UZ series, 2 pads Capacitance: 100µF, Tolerance ±20%, Voltage 35V, Case size: ØD8.0*L10.20mm, Impedance 0.19 Ohm., Ripple Current: 450mA Max. @+105℃, 100KHz, Lifetime 2000Hours @105°C, Operating Temp. Range -55°C ~+105°C

• Polar Aluminum Electrolytic Capacitor (Foil Type)
• High stability and reliability
• Lifetime 2000 Hours @ 105°C
• Designed Capacitor’s Quality Meets IEC60384.
• Applicable To Automatic Mounting Machine
• Cross Competitors Parts and more.
• RoHS Complaint And Halogen Free

APPLICATION

• High-density Patch Assembly General Electronic Circuit, such as power supply, lighting, etc

Specification

Series

UZ

Capacitance

100µF

Capacitance Tolerance

±20%

Rated Voltage

35V

Case Size

Ø8.0*L10.2mm

Impedance @20℃,100KHz

0.19ohm Max.

Ripple Current @+105°C, 100KHz

450mA Max.

Lifetime @105°C

2000 Hours

Operating Temp. Range

-55°C ~+105°C

Dissipation Factor @+105°C, 120KHz

0.12 Tanδ Max.

Leakage Current Max.

52.5 (μA)max

Mounting Type

Surface Mount, 2 pads

RoHS Status

RoHS III Compliant & Halogen Free

Moisture Sensitivity Level (MSL)

1 (Unlimited)

REACH Status

REACH Unaffected

HTSUS

8532.22.0020

ECCN

EAR99

Standard Package (MPQ)

500pcs/Reel, Quantity entered must be multiple of 500

NCNR

Non-Cancelable/Non-Returnable
