35V 330µF ±20% 14 mohm Max. 3500mA 4K hours AEC-Q200 BZ Series

Conductive Polymer Hybrid Aluminum Electrolytic Capacitors BZ series, Capacitance: 330µF, Tolerance ±20%, Voltage 35V, 2 pads, Case size: ØD10*L12.5mm, Ripple Current 3500mA Max.@+125℃, 100KHz, Lifetime 4000Hours @125°C, ESR @125°C,100KHz: 14 mohm Max. Operating Temp. Range -55°C ~+125°C, Leakage Current: 115μA @at 20℃ after 2 minutes

Key Features:
  • Series: BZ
  • Capacitance: 330µF
  • Capacitance Tolerance: ±20%
  • Rated Voltage: 35V
  • Impedance @20℃,100KHz: 14mohm Max.
  • Ripple Current @+125°C, 100KHz: 3500mA Max.
  • Lifetime @125°C: 4000 Hours
  • Rating: AEC-Q200

$4.85550

Out of stock
SKU BZ337M035HGMTA
Original MPNCXE337M1VHBZG1BTR
Datasheet Data Sheet

Description

Conductive Polymer Hybrid Aluminum Electrolytic Capacitors BZ series, Capacitance: 330µF, Tolerance ±20%, Voltage 35V, 2 pads, Case size: ØD10*L12.5mm, Ripple Current 3500mA Max.@+125℃, 100KHz, Lifetime 4000Hours @125°C, ESR @125°C,100KHz: 14 mohm Max. Operating Temp. Range -55°C ~+125°C, Leakage Current: 115μA @at 20℃ after 2 minutes

• Conductive Polymer Hybrid Aluminum Electrolytic Capacitors
• High Stability And Reliability, Low ESR, High Ripple Current
• Long Life 4000 Hours @ 125°C
• Quality and standard Meets IEC 60384-4 and AEC-Q200-REV D
• Applicable To Automatic Mounting Machine
• Cross Competitors PARTS GYA, HZC, ZC And HXC Series And More.
• RoHS III Complaint And Halogen Free

APPLICATION

• For Applications Automotive and more

Specification

Series

BZ

Capacitance

330µF

Capacitance Tolerance

±20%

Rated Voltage

35V

Case Size

ØD10.00*L12.5mm

Impedance @20℃,100KHz

14mohm Max.

Ripple Current @+125°C, 100KHz

3500mA Max.

Lifetime @125°C

4000 Hours

Operating Temp. Range

-55°C ~+125°C

Dissipation Factor @+20°C, 120KHz

12.0 Tanδ Max.

Leakage Current (μA/2min) µA Max

115μA

Mounting Type

Surface Mount, 2 pads

Rating

AEC-Q200

RoHS Status

RoHS III Compliant & Halogen Free

Moisture Sensitivity Level (MSL)

1 (Unlimited)

REACH Status

REACH Unaffected

HTSUS

8532.22.0020

ECCN

EAR99

Standard Package (MPQ)

400pcs/Reel, Quantity entered must be multiple of 400

NCNR

Non-Cancelable/Non-Returnable
