35V 4.7µF ±20% 15mA 2K Hours UT Series

SMD Aluminum Electrolytic Capacitors, Wide Temperature Standard Type, UT series, 2 pads Capacitance: 4.7µF, Tolerance ±20%, Voltage 35V, Case size: ØD4.0*L5.40mm, Ripple Current 18mA Max. @+105℃, 120Hz, Lifetime 2000Hours @105°C, Operating Temp. Range -55°C ~+105°C

Key Features:
  • Series: UT
  • Capacitance: 4.7µF
  • Capacitance Tolerance: ±20%
  • Rated Voltage: 35V
  • Ripple Current @+105°C, 120Hz: 18mA Max.
  • Lifetime @105°C: 2000 Hours
  • Leakage Current @20 °C: 3.0µA Max.

$0.13500

40000 in stock
SKU UT475M035HCHTA
Original MPNCAE475M1VHUTCE4TRC
Datasheet Data Sheet
Add to wishlist

Description

SMD Aluminum Electrolytic Capacitors, Wide Temperature Standard Type, UT series, 2 pads Capacitance: 4.7µF, Tolerance ±20%, Voltage 35V, Case size: ØD4.0*L5.40mm, Ripple Current 18mA Max. @+105℃, 120Hz, Lifetime 2000Hours @105°C, Operating Temp. Range -55°C ~+105°C

• Polar Aluminum Electrolytic Capacitor (Foil Type)
• High stability and reliability
• Lifetime 2000 Hours @ 105°C
• Designed Capacitor’s Quality Meets IEC60384.
• Applicable To Automatic Mounting Machine
• Cross Competitors Parts FN, FKS, MVE UUT SKV, SGV Series and more.
• RoHS Complaint And Halogen Free

APPLICATION

• High-density Patch Assembly General Electronic Circuit Etc.

Specification

Series

UT

Capacitance

4.7µF

Capacitance Tolerance

±20%

Rated Voltage

35V

Case Size

ØD4.0*L5.40mm

Ripple Current @+105°C, 120Hz

18mA Max.

Lifetime @105°C

2000 Hours

Operating Temp. Range

-55°C ~+105°C

Dissipation Factor @+20°C, 120Hz

0.16 Tanδ Max.

Leakage Current @20 °C

3.0µA Max.

Mounting Type

Surface Mount, 2 pads

RoHS Status

RoHS III Compliant & Halogen Free

Moisture Sensitivity Level (MSL)

1 (Unlimited)

REACH Status

REACH Unaffected

HTSUS

8532.22.0020

ECCN

EAR99

Standard Package (MPQ)

2000pcs/Reel, Quantity entered must be multiple of 2000

NCNR

Non-Cancelable/Non-Returnable
