Name: 35V 47µF ±20% 0.85ohm 150mA 2K Hours UE Series
SKU: UE476M035HEJTA
Price: 0.24 USD
Availability: OutOfStock

Welcome to Aillen Capacitors !

Hello, Log In My Account

0 Shopping Cart $0.00000

SMD Aluminum Electrolytic Capacitors, Low ESR/Impedance type, UE series, 2 pads Capacitance: 47µF, Tolerance ±20%, Voltage 35V, Case size: ØD6.3*L7.70mm, Impedance 0.85Ω, 2000 Hours, RC: 150 mA (at 105 ℃,100KHz), Operating Temp. Range -55°C ~+105°C

Key Features:

Series: UE
Capacitance: 47µF
Capacitance Tolerance: ±20%
Rated Voltage: 35V
Ripple Current @+105°C, 100KHz: 150mA Max.
Lifetime @105°C: 2000 Hours
Leakage Current: 16.45 (μA)max
Impedance @20℃,100KHz: 0.85ohm Max.

See Full Specification

$0.23500

Out of stock

SKU	UE476M035HEJTA

Original MPN	CAE476M1VHUEEG7TRC
Datasheet	Data Sheet

Description
Specification

Description

• SMD Aluminum Electrolytic Capacitors
• Wide Temperature
• Low Impedance & ESR
• Designed For SMD On PCB
• Applicable To Automatic Mounting Machine
• RoHS Complaint And Halogen Free

APPLICATION

• High-density Patch Assembly Electronic Circuit, Power Supply, Lighting, Etc

Specification

Series	UE
Capacitance	47µF
Capacitance Tolerance	±20%
Rated Voltage	35V
Case Size	Ø6.30*L7.70mm
Ripple Current @+105°C, 100KHz	150mA Max.
Lifetime @105°C	2000 Hours
Operating Temp. Range	-55°C ~+105°C
Dissipation Factor @+20°C, 120Hz Tanδ Max.	0.12 Tanδ Max.
Leakage Current	16.45 (μA)max
Impedance @20℃,100KHz	0.85ohm Max.
Mounting Type	Surface Mount, 2 pads
RoHS Status	RoHS III Compliant & Halogen Free
Moisture Sensitivity Level (MSL)	1 (Unlimited)
REACH Status	REACH Unaffected
HTSUS	8532.22.0020
ECCN	EAR99
Standard Package (MPQ)	1000pcs/Reel, Quantity entered must be multiple of 1000
NCNR	Non-Cancelable/Non-Returnable
