35V 470µF ±20% 11 mohm Max. 4000mA 4K hours AEC-Q200 BZ Series

Conductive Polymer Hybrid Aluminum Electrolytic Capacitors BZ series, Capacitance: 470µF, Tolerance ±20%, Voltage 35V, 2 pads, Case size: ØD10*L16.5mm, Ripple Current 4000mA Max.@+125℃, 100KHz, Lifetime 4000Hours @125°C, ESR @125°C,100KHz: 11 mohm Max., Operating Temp. Range -55°C ~+125°C, Leakage Current: 164μA @at 20℃ after 2 minutes

Key Features:
  • Series: BZ
  • Capacitance: 470µF
  • Capacitance Tolerance: ±20%
  • Rated Voltage: 35V
  • Impedance @20℃,100KHz: 11mohm Max.
  • Lifetime @125°C: 4000 Hours
  • Rating: AEC-Q200
See Full Specification

$7.85000

Out of stock
SKU BZ477M035HGOTA
Original MPNCXE477M1VHBZGP5TR
Datasheet Data Sheet

Description

Conductive Polymer Hybrid Aluminum Electrolytic Capacitors BZ series, Capacitance: 470µF, Tolerance ±20%, Voltage 35V, 2 pads, Case size: ØD10*L16.5mm, Ripple Current 4000mA Max.@+125℃, 100KHz, Lifetime 4000Hours @125°C, ESR @125°C,100KHz: 11 mohm Max., Operating Temp. Range -55°C ~+125°C, Leakage Current: 164μA @at 20℃ after 2 minutes

  • Conductive Polymer Hybrid Aluminum Electrolytic Capacitors
  • High Stability And Reliability, Low ESR, High Ripple Current
  • Long Life 4000 Hours @ 125°C
  • Quality and standard Meets IEC 60384-4 and AEC-Q200-REV D
  • Applicable To Automatic Mounting Machine
  • Cross Competitors PARTS GYA, HZC, ZC And HXC Series And More.
  • RoHS III Complaint And Halogen Free

APPLICATION

  • For Applications Automotive and more
