SMD Aluminum Electrolytic Capacitors, Low ESR type, UE series, 2 pads Capacitance: 100µF, Tolerance ±20%, Voltage 50V, Case size: Ø8.00*L10.2mm, Impedance 0.85Ω, 2000 Hours, Operating Temp. Range -55°C ~+105°C
SMD Aluminum Electrolytic Capacitors, Low ESR type, UE series, 2 pads Capacitance: 100µF, Tolerance ±20%, Voltage 50V, Case size: Ø8.00*L10.2mm, Impedance 0.85Ω, 2000 Hours, Operating Temp. Range -55°C ~+105°C
• SMD Aluminum Electrolytic Capacitors
• Designed for SMD on PCB
• Applicable to automatic mounting machine
• RoHS Complaint and Halogen Free
APPLICATION
• High-density Patch Assembly Electronic Circuit, Power Supply, Lighting, Etc.
| Series | UE |
|---|---|
| Capacitance | 100µF |
| Capacitance Tolerance | ±20% |
| Rated Voltage | 50V |
| Case Size | Ø8.00*L10.2mm |
| Ripple Current @+105°C, 100KHz | 185mA Max. |
| Lifetime @105°C | 2000 Hours |
| Operating Temp. Range | -55°C ~+105°C |
| Dissipation Factor @+20°C, 120Hz Tanδ Max. | 0.12 Tanδ Max. |
| Leakage Current | 50 (μA)max |
| Impedance @20℃,100KHz | 0.85ohm Max. |
| Mounting Type | Surface Mount, 2 pads |
| RoHS Status | RoHS III Compliant & Halogen Free |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| HTSUS | 8532.22.0020 |
| ECCN | EAR99 |
| Standard Package (MPQ) | 500pcs/Reel, Quantity entered must be multiple of 500 |
| NCNR | Non-Cancelable/Non-Returnable |
