Name: 50V 22µF ±20% 80 mohm Max. 750mA 4K hours AEC-Q200 BW Series
SKU: BW226M050HEHTA
Price: 1.86 USD
Availability: OutOfStock

Welcome to Aillen Capacitors !

Hello, Log In My Account

0 Shopping Cart $0.00000

Conductive Polymer Hybrid Aluminum Electrolytic Capacitors BW series, Capacitance: 22µF, Tolerance ±20%, Voltage 50V, 2 pads, Case size: ØD6.3*L5.8mm, Ripple Current 750mA Max.@+125℃, 100KHz, Lifetime 4000Hours @125°C, ESR @125°C,100KHz: 80 mohm Max., Operating Temp. Range -55°C ~+125°C, Leakage Current: 11.0μA @at 20℃ after 2 minutes

Key Features:

Series: BW
Capacitance: 22µF
Capacitance Tolerance: ±20%
Rated Voltage: 50V
Impedance @20℃,100KHz: 80mohm Max.
Lifetime @125°C: 4000 Hours
Rating: AEC-Q200

See Full Specification

$1.85550

Out of stock

SKU	BW226M050HEHTA

Original MPN	CXE226M1HHBWEE8TRC
Datasheet	Data Sheet

Description
Specification

Description

• Conductive Polymer Hybrid Aluminum Electrolytic Capacitors
• High Stability And Reliability, Low ESR, High Ripple Current
• Long Life 4000 Hours @ 125°C
• Quality and standard Meets IEC 60384-4 and AEC-Q200-REV D
• Applicable To Automatic Mounting Machine
• Cross Competitors PARTS GYA, HZC, ZC And HXC Series And More.
• RoHS III Complaint And Halogen Free

APPLICATION

• For Applications Automotive and more

Specification

Series	BW
Capacitance	22µF
Capacitance Tolerance	±20%
Rated Voltage	50V
Case Size	ØD6.30*L5.80mm
Impedance @20℃,100KHz	80mohm Max.
Ripple Current @+125°C, 100KHz	750mA Max.
Lifetime @125°C	4000 Hours
Operating Temp. Range	-55°C ~+125°C
Dissipation Factor @+20°C, 120KHz	10.0 Tanδ Max.
Leakage Current (μA/2min) µA Max	11.0μA
Mounting Type	Surface Mount, 2 pads
Rating	AEC-Q200
RoHS Status	RoHS III Compliant & Halogen Free
Moisture Sensitivity Level (MSL)	1 (Unlimited)
REACH Status	REACH Unaffected
HTSUS	8532.22.0020
ECCN	EAR99
Standard Package (MPQ)	1000pcs/Reel, Quantity entered must be multiple of 1000
NCNR	Non-Cancelable/Non-Returnable
