Description
SMD Aluminum Electrolytic Capacitors, FZ series, 2 pads, Capacitance: 4.7µF, Tolerance ±20%, Voltage 63V, Case size: ØD5.0*L5.7mm, Ripple Current 60 mA Max. @+105℃, 100KHz, Lifetime 2000Hours @105°C, ESR @20°C,100KHz: 2.9 ohm Max., Operating Temp. Range -55°C ~+105°C. Surge Voltage: 57.5V, Leakage Current: 3.0μA @at 20℃ after 2 minutes
• Polar Aluminum Electrolytic Capacitor (Foil Type)
• High stability and reliability
• Lifetime 2000 Hours @ 105°C
• Designed Capacitor’s Quality Meets IEC60384.
• Applicable To Automatic Mounting Machine
• Cross Competitors Parts
• RoHS Complaint And Halogen Free
APPLICATION
• High-density Patch Assembly General Electronic Circuit Etc.
